Eaton UPS 5P1550i Gen2, Line interactive, Rack 1U, 1550VA/1350W,Input C14, Outputs 6 x C13, USB port, Serial port, Rail kit, 2 x IEC-IEC cables, Network card slot, Warranty 3yr on electrenoci, 2yr on battery
DETALJNE SPECIFIKACIJE:
| UPS Technology | Line Interactive |
| Output Power Capacity | 1350 W |
| Maximum Electrical Power Rating | 1550 VA |
| Nominal Output Voltage | 200/208/220/230/240 V |
| Standardi | IEC/EN 62040-1; IEC/EN 62040-2; IEC/EN 62040-3; UL 1778; CSA-C22.2; CE; UKCA; Cm; Ukr; KCC; cTUVus; BIS |
| Voltage Phase | Single |
| Status Notification Method | LCD |
| Power Features | Automatic Voltage Regulator Advanced Battery Management (ABM) |
| Output Waveform | Sinewave |
| Maximum Output Voltage | 240 V |
| Minimum Output Voltage | 200 V |
| Maximum Output Frequency | 60 Hz |
| Minimum Output Frequency | 50 Hz |
| Output Power Connectors Quantity | 6 |
| Output Power Connectors Type | IEC-320 C13 |
| Max. ulazni napon | 294 V |
| Min. ulazni napon | 150 V |
| Max. ulazna frekvencija | 70 Hz |
| Min. ulazna frekvencija | 47 Hz |
| Input Power Connectors Quantity | 1 |
| Priključci napajanja | IEC-320 C14 |
| Battery Location | Plug-in modul |
| Baterija | 1 |
| Maximum Battery Supported Quantity | 1 |
| Kapacitet | 9 Ah |
| Battery Backup Time at Half Load | 13.5 min |
| Battery Recharge Time | 2 min |
| Max. radna temperatura | 40 °C |
| Max. radna vlažnost | 90 % |
| Min. radna temperatura okoline | 0 °C |
| Min. radna vlažnost | 0 % |
| Tipična radna razina buke | 35 dB |
| Boja | Crna |
| Postavljanje | Rackmount |
| Standard Rack Height | 1 U |
| Dodaci | Rack Mounting Kit Cable Locking Systems Brzi priručnik Sigurnosni list |
| Kabeli | USB kabel 2 x Power Cables |
| Dubina (mm) | 555 mm |
| Visina (mm) | 43.2 mm |
| Širina (mm) | 438 mm |
| Težina | 18.7 kg |
| Jamstvo u Hrvatskoj | Da |
| Jamstveni rok (mjeseci) | 36 mjeseci(a) |
| Validacija jamstva | Serijski broj |
| Dužina (mm) | 1 mm |
| Širina (mm) | 1 mm |
| Visina (mm) | 1 mm |
| Bruto težina (kg) | 21 kg |
| Neto težina (kg) | 19 kg |
| Količina u pakiranju | 1 |
| Bruto težina kutije (kg) | 21 kg |
| Količina u kutiji | 1 |
