| maging | |
| Lens Mount | Canon RF |
| Lens Communication | Yes: Cooke /i |
| Image Sensor | Full-Frame CMOS |
| Sensor Resolution | Effective: 34 Megapixel (7144 x 4790) |
| Capture Type | Stills & Video |
| Exposure Control | |
| Shutter Type | Electronic Rolling Shutter |
| Shutter Speed | 1/16000 to 30 Seconds |
| Shutter Angle | 11.25 to 360° |
| ISO/Gain Sensitivity | Native in Auto Mode: 800 to 6400 |
| Native in Auto Mode: 400 to 3200 |
| Native in Auto Mode: 160 to 1250 |
| Advertised Dynamic Range | 15 Stops |
| 16 Stops |
| Exposure Modes | Auto, Manual |
| Focus | |
| Focus Modes | Automatic, Manual Focus |
| Video Capture | |
| Internal Recording | Raw 12-Bit |
| 6960 x 4640 at 23.98/24.00/25/29.97 fps |
| 6960 x 3672 at 23.98/24.00/25/29.97/50/59.94 fps |
| Raw 12-Bit |
| 5036 x 2656 at 23.98/24.00/25/29.97/50/59.94 fps |
| 2524 x 1332 at 23.98/24.00/25/29.97/50/59.94 fps |
| *Sensor Crops Video |
| H.264/MPEG-4/XF-AVC S 4:2:2 10-Bit |
| 4096 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
| 3840 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
| H.264/MPEG-4/XF-AVC S 4:2:0 8-Bit |
| 4096 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
| 3840 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
| 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps |
| 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps |
| XF-AVC 4:2:2 10-Bit |
| 4096 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
| 3840 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
| 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps |
| 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps |
| XF-HEVC S 4:2:2 10-Bit |
| 6912 x 4608 at 23.98/24.00/25/29.97 fps |
| 4096 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
| 3840 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
| 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps |
| 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps |
| XF-HEVC S 4:2:0 10-Bit |
| 6912 x 4608 at 23.98/24.00/25/29.97 fps |
| 4096 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
| 3840 x 2160 at 23.98/24.00/25/29.97/50/59.94 fps |
| 2048 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps |
| 1920 x 1080 at 23.98/24.00/25/29.97/50/59.94 fps |
| Fast-/Slow-Motion Support | Yes |
| Gamma Curve | Canon Log 2, Canon Log 3, Hyper Gamma |
| Audio Recording | Raw, XF-AVC: 4-Channel, 24-Bit at 48 kHz via LPCM Audio |
| XF-HEVC S: 2-Channel, 16-Bit at 48 kHz via AAC LC Audio |
| XF-HEVC S: 4-Channel, 24-Bit at 48 kHz via LPCM Audio |
| XF-AVC S: 2-Channel, 16-Bit at 48 kHz via AAC LC Audio |
| XF-AVC S: 4-Channel, 24-Bit at 48 kHz via LPCM Audio |
| Interface | |
| Media/Memory Card Slot | Slot 1: SD/SDHC/SDXC |
| Slot 2: CFexpress Type B (CFast 2.0) [VPG-400 or Faster Recommended] |
| Video I/O | 1x HDMI Output |
| Audio I/O | 1x 1/8″ / 3.5 mm TRS Stereo Microphone Input on Camera Body (Plug-in Power) |
| 1x 1/8″ / 3.5 mm TRS Stereo Headphone Output |
| 1x XLR 3-Pin Microphone Input on Included Handle |
| 1x XLR 3-Pin Line Input on Included Handle |
| Other I/O | 1x 2.5 mm Sub-Mini (Remote) Control |
| 1x USB-C |
| 1x DIN 1.0/2.3 (Timecode) Input/Output |
| 1x Proprietary |
| Wireless | Wi-Fi / 2.4 GHz Radio/RF / 5.8 GHz Radio/RF |
| Mobile App Compatible | Yes: Android & iOS |
| App Name: Canon App |
| Monitor | |
| Display Type | Articulating 3″ Non-Touchscreen LCD |
| Viewfinder | |
| EVF Interface | No-Dedicated EVF Options (Must use video out) |
| Power | |
| Battery Type | Canon LP-E6, Canon LP-E6NH |
| DC Power Input | Dummy Battery Only |
| Environmental | |
| Operating Conditions | 23 to 113°F / -5 to 45°C at 60 to 85% Humidity |
| General | |
| Shoe Mount | 1x Intelligent Hot Shoe |
| Dimensions (W x H x D) | 5.6 x 3.5 x 3.7″ / 143 x 88 x 95 mm |
| 8.7 x 9.4 x 7.3″ / 222 x 239 x 186 mm (With Handle, Mic Holder) |
| Weight | 23.5 oz / 665 g (Body Only) |
| 2.4 lb / 1110 g (With Battery, Handle, Recording Media) |
